Description
| Specifications | |
|---|---|
| Model | 3004362 |
| Condition | Used |
| Other Specifications |
|---|
|
Type: Feed Through
Number of Positions: 2
Number of Levels: 1
Terminal - Width: 6.2mm
Termination Style: Screw
Current - IEC: 32 A
Voltage - IEC: 800V
Current - UL: 30 A
Voltage - UL: 600V
Wire Gauge or Range - AWG: 10-30 AWG
Wire Gauge or Range - mm²: 0.2-6mm²
Material - Insulation: Polyamide (PA), Nylon
Material Flammability Rating: UL94 V-0
Stripping Length: 8mm
|
