Description
| Specifications | |
|---|---|
| Model | 5SJ4102-7HG40 |
| Made In | GERMANY |
| Condition | Surplus New | General |
| Amps | 2 amps |
| Series | Sentron |
| # of Poles | 1 |
| Mounting Style | Plug-In |
| Voltage | 240 volts |
| Phase | Single-phase |
| AFCI | No |
| GFCI | No |
| Other Specifications |
|---|
|
Technical Data RoHS-compliant: Yes Nominal current - rounded value: 2 A Nominal current: 2 A Factory colour: Grey Dim: (W x H x D) 18 x 90 x 70 mm Depth: 70 mm Height: 90 mm Width: 18 mm Compatible with (details): SENTRON Switch-off capacity: 14 kA Number of pins: 1 Release characteristics: C Operating voltage: 240 V Built-in depth: 70 mm Rated current: 2 A Rated voltage: 400 V Frequency: 50-60 MHz Over voltage category: 3 Pollution degree: 3 Width in number of modular spacings: 1 Number of protected poles: 1 Number of poles (total): 1 Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: 10 kA Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: 10 kA Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: 15 kA Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: 15 kA |
