GL&V Bowscreen TS3 Rejects Thickener 48" x 196"
GL&V

Bowscreen TS3 Rejects Thickener 48" x 196"

SKU: 112228
Price:
$15,038

Shipping calculated at checkout

Stock:
4 in Stock
Make an Offer

Need An Answer Now?

604-449-1880
Finance
Amount:
For more information, please contact finance@lenmark.com or reach out to your sales rep.
Email Finance

Description

The TS Bow Screen is a simple and effective unit capable of separating fiber as small as 100 microns in length from a water suspension. Police filter, thickener, felt hair remover, ash remover.
Specifications
Model BOWSCREEN TS3
Year: 2017
Condition Used
Weight + Dimensions
Diameter 48"
General
Application rejects thickening
Other Specifications

PDF TECHNICAL DRAWINGS

PDF INSTRUCTION MANUAL

Principle of Operation:

  • The decker consists of a wire mesh covered cylinder (mould) rotating in a vat of stock.
  • Level differences between the inside and outside of the mould induce a drainage of water from the stock.
  • Stock is fed into one side of the vat and passes under the mould, forming a mat on the wire.
  • This mat is picked off by a rubber covered couch roll and sliced off by a doctor blade running the length of the roll. The thickened stock so removed, creeps over the doctor blade and falls from the apron into a discharge chute.
  • White water drained into the cylinder mould passes through the end of the decker and out through a pipe.

Diameter: 48"

Length of Cylinder Mould: 196"
