Description
| Specifications | |
|---|---|
| Model | DS0200.B2A04K.22K2 |
| S/N: | 083352B-19 |
| Made In | MALAYSIA |
| Condition | Used |
| Other Specifications |
|---|
|
Maximum Operating Pressure: 120 PSIG
Temperature Range: -40F/175F
Tapped Mounting Bolt Holes: UNC (Standard Bettis Trim, ISO 5211 with UNC bolt holes on valve mounting side, Metric bolt holes on NAMUR patterns NPT ports)
Travel Stops: Dual Travel Stops (Standard Bettis Trim for all models except for 0012)
Assembly Modes: Standard Bettis Trim Fail-CW (Mounted in line, standard)
Color Code: Bettis orange
Indication Knob: Visual Indication (Knob, Standard)
Operating media: Air, dry or lubricated and inert gasses.Air, dry or lubricated and inert gasses. Dew point 10 K below operating temperature. For temperatures below 32°F (0°C) take appropriate measures to prevent freezing of condensate.
Lubrication: Factory lubricated for the normal life of the actuator
Construction: Suitable for indoor and outdoor installation.
Finish: Polyester non-TGIC based powder coating
|
