Description
| Specifications | |
|---|---|
| Model | TCXI7800-403EN |
| Condition | Surplus New |
| Other Specifications |
|---|
|
Accuracy: 0.25% Full Scale Guaranteed, 0.15% Full Scale Typical Action Type: Reversible Air Connection: 1/4 in. Female Threaded (Inlet/Outlet) Air Flow Rate: 9 SCFM at 120 psig Applicable Standard: Class I Div 1 Group B/C/D, Class I Div 2 Group A/B/C/D, Class II Div 1 Group E/F/G, Class III Div 1 Fiber, FM Application: Indoor/Outdoor Body Material: Epoxy-Powder Coated Chromate-Treated Aluminum Dimensions: 3-11/16 in. W x 3-13/16 in. Diam. x 4-5/8 in. H Input Signal: 4 to 20 mA DC Mounting Method: (2) 1/4 in.-20 UNC Pressure Rating: 35 to 120 psig Product Type: Electro-Pneumatic Transducers Temperature Rating: -40 to 160 °F Output: 6 to 30 psig |
