Description
| Specifications | |
|---|---|
| Model | 632.34 |
| Made In | SWITZERLAND |
| Condition | Surplus New | General |
| Gauge Type | Pressure |
| Filling | Dry |
| Pressure Rating | 0-5 psi | Weight + Dimensions |
| Size | 4.5" |
| Thread Size | 1/2" NPT |
| Other Specifications |
|---|
|
Design: ASME B40.100 Accuracy Class: +/-2/12% of span (ASME B40.100 Grade A) Ranges: 6X2.34: 10" H2O to 250" H2O (600 mbar) or other equivalent units of pressure or vacuum Working Pressure: Steady - Full scale value; Fluctuating - 0.9 x full scale value Operating Temperature: Ambient: -4 deg. F to 140 deg. F; Medium: 212 deg. F Weather Protection: Weather resistant (NEMA 3/IP54) Pressure Connection: 316L SS, Lower Mount, 1/2" NPT Capsule Element: 316L SS Movement: Stainless Steel Dial: White aluminum with black lettering, stop pin at 6 o' clock Pointer: Black aluminum, adjustable Case: Black- fiberglass reinforced thermoplastic (POCAN), Solid front/blowout back safety case design, Turret style case with built in rear flange lugs Window: Clear acrylic with Buna-N gasket |
