Description
| Specifications | |
|---|---|
| Model | T432T10-30 XFS |
| Made In | CANADA |
| Condition | Used | Electrical |
| Voltage | 120/240 volts |
| Other Specifications |
|---|
|
Set Repeatability (Accuracy): +/-% of span Switch Type: SPDT or 2 SPDT acting as DPDT Setpoint: Single setpoint - factory set or field adjustable Deadband: Fixed or limited adjustable deadband Enclosure Material: Watertight - epoxy coated aluminum; Explosion - epoxy coated aluminum, 316SS (opt.) Pressure Connection Size:-
Electrical Termination: 3/4 NPT Female Direct Mount: Stem Lengths from 2-3/4" to 24" Remote Mount: Capillary lengths from 5' to 25' (5ft. increments) Wetted Components:
Enclosure: Watertight Enclosure meets NEMA 3, 4, 4X, 13 and IP66 requirements Switch Element: Hermetically sealed switch, gold contacts, 1A, 125 VAC Thermal System: 10' Bulb Length: 3" Temperature Range: 75 deg. to 205 deg. F |
