Description
| Specifications | |
|---|---|
| Model | 23152 CACK/HA3C4W33 |
| Condition | Surplus New | General |
| Bore Size (Metric) | 260 mm |
| Bore Size (Imperial) | 10.23 in |
| Outside Diameter (Metric) | 440 mm |
| Outside Diameter (Imperial) | 17.32 in |
| Bearing Type | Spherical |
| Other Specifications |
|---|
|
Internal Clearance: C4 (greater than normal clearance for high temperature or speed applications) Cage Type: HA3 (special cage and heat treatment for high-temp stability) Lubrication Feature: W33 (oil groove and holes in outer ring) Material: High-grade bearing steel Dynamic Load Rating (C): 1500 kN (approximate, varies slightly by design revision) Static Load Rating (C0): 1500 kN (approximate) Limiting Speed (Grease): approx.1000 RPM Limiting Speed (Oil): approx. 1300 RPM |
