Description
| Specifications | |
|---|---|
| Model | SNH 524-620 |
| Condition | Used | General |
| Type | Split Plummer Block |
| Height | 271 mm |
| Outside Length | 410 mm |
| Base to Bore Centerline | 140 mm |
| Distance Between Bolts | 350 mm |
| Housing Compatible Bore Diameter | 215 mm |
| Other Specifications |
|---|
|
Properties Housing type: Plummer/pillow block Housing configuration: Two-piece Mounting arrangement: Through shaft/Shaft end Number of bolt holes for fasteners: 2 Material, housing: Cast iron Bearing housing seal type: Without Housing lubrication feature/possibility: Grease Materials Housing material: Cast iron Corrosion protection: Paint - in accordance with ISO 12944-2, corrosivity category C2 Mounting informationRecommended diameter of attachment bolts: 24 mm Recommended tightening torque for attachment bolts: 665 Nm Size of cap bolts: M20x120 Tightening torque for cap bolts: 200 Nm Size of eye bolt: M10 Initial grease fill, 20%: 630 g Initial grease fill, 40%: 1 000 g |
