SKF FY 3/4 TF Ball Bearing Flange Unit, 4 Bolts, Setscrew Locking, Regreasable, Contact and Flinger Seal, Cast Iron, Inch, 3/4" Bore, 2-1/2" Bolt Hole Spacing Width, 2860lbf Dynamic Load Capacity
| Specifications |
| Model |
FY 3/4 TF |
| Made In |
MEXICO |
| Condition |
Surplus New |
| Other Specifications |
|
Overview:
- Inner Diameter (mm): 19.050
- Outer Diameter (mm): 86.000
- Width (mm): 37.300
- Dimension Type: Inch
- Lubricant (in Bearing): Grease
- Bearing Bore Type: Cylindrical
- Bearing Sealing: Seal and flinger on both sides
- Fastening Bolt Hole Type (Housing): Plain holes
- Housing Material: Cast iron
- Relubrication Nipple: With
- Unit Sealing: Without
|
