Description
| Specifications | |
|---|---|
| Model | 3RU2116-1EB0 |
| Made In | GERMANY |
| Condition | Used | General |
| Amps | 2.8-4 amps |
| Other Specifications |
|---|
|
FLC Motor Rating: 2.8 ? 4 A
Contact Current Rating: 4 A
Range: Sirius Innovation
Pole Configuration: 3P
Series: 3RU
Mounting Style: Direct Contactor
Power Rating: 1.5 kW
Normal State Configuration: NO/NC
Reset Method: Automatic, Manual
Terminal Type: Screw
Number Of Auxiliary Contacts: 2
Maximum Operating Temperature: +70°C
Minimum Operating Temperature: -40°C
Operating Temperature Range: -40 ? +70 °C
Contact Voltage Rating: 690 V ac
Product Details
Switch position indicator and test function
STOP button
Selector switch for manual/automatic reset
Screw connection or Spring-clamp versions
Impulse voltage resistance 6 kV
Insulation voltage 690V
Surface or DIN-rail stand-alone mounts available, see 706-1699 etc
The 3RU21 thermal overload relays up to 80 A have been designed for current-sensitive protection of loads with normal starting.
These thermal overload relays for use with Sirius Size S0 & S00 Contactors
Note
Screw terminals can only be used with screw terminal overloads and spring terminals can only be used with spring terminal overloads.
|
