Description
Specifications | |
---|---|
Model | 91-34F51T09L1 |
Year: | 2011 |
S/N: | 732007 |
Condition | Used | General |
Diameter | 1-1/2" |
Valve Style | Pressure Relief |
Body | WCB Carbon Steel |
Other Specifications |
---|
Standard Inlet Size: 1-1/2" Inlet and Outlet Connection Type: 1-1/2" MNPT x 1-1/2" FNPT Actual Orifice Diameter: 0.655 in Actual Orifice Area: 0.337 in2 API Orifice Area: 0.307 in2 Pressure Range: 15-2400 psig Standard Temperature Range: -20 deg. F to 400 deg. F ASME Flow Coefficient Kd (Gas): 0.818 ASME Flow Coefficient Kd (Liquid): 0.707 Inlet Base & Body Material: Carbon Steel / WCB Carbon Steel Cap Type: Closed Cap Seat Material: PTFE Spring Code: 09 Trim: 316 S.S. Disk & Nozzle (Liquid Service) O-Ring Material: FKM & BUNA-N (Standard) |
