Description
| Specifications | |
|---|---|
| Model | G2112B1411 |
| Year: | 2001 |
| S/N: | G11968-3 |
| Condition | Used | Electrical |
| kVA | 11870 kVA |
| Primary Voltage | 25000 volts |
| Secondary Voltage | 4160/2400 volts |
| Phase | 3-phase | General |
| Transformer Type | Power Transformer |
| Auto VS Isolation | Isolation |
| Oil vs Dry | Oil |
| Other Specifications |
|---|
|
Frequency: 60 Hz Cooling Class: ONAN / ONAF Connection: HV: Delta, LV: Wye Impedance: 6.18 % at 7.50 MVA Full wave impulse level: HV: 125 kV, LV: 60 kV Insulation Class: 65 °C rise Coolant: Non-PCB, Class B, Type I, Mineral Oil Tank will withstand full vacuum: yes |
