Description
| Specifications | |
|---|---|
| Model | 01036ET3H215TC-W22 |
| Made In | MEXICO |
| Condition | Used | General |
| Current Type | AC |
| Horsepower | 10 hp |
| Voltage | 575 volts |
| RPM | 3530 rpm |
| Frame | 213/5TC | Additional Data |
| Duty | Continuous |
| Other Specifications |
|---|
|
Number of Poles: 2
Slip: 1.94 %
Rated voltage: 575 V
Rated current: 9.28 A
L. R. Amperes: 66.8 A
LRC: 7.2x(Code H)
No load current: 2.88 A
Rated torque: 14.9 ft.lb
Locked rotor torque: 220 %
Breakdown torque: 290 %
Locked rotor time: 32s (cold) 18s (hot)
Moment of inertia (J): 0.6362 sq.ft.lb
Design: B
Insulation Class: F
Service factor: 1.25
Temperature rise: 80 K
Duty Cycle: Cont.(S1)
Starting Method: Direct On Line
Ambient temperature: -20°C to +40°C
Altitude: 1000 m.a.s.l.
Degree of Protection: IP55
Enclosure: IC411 - TEFC
Mounting: F-1
Rotation: Both (CW and CCW)
Noise level: 68.0 dB(A)
Features
Frame Material: Cast Iron
Impregnation Method: Dip and Bake Polyester
Main terminal box hole: NPT 1"
Terminal Block: Without
Shaft Locking Device: Without
Drain: Rubber, automatic
Shaft Material: SAE 1040/45 Carbon Steel
Painting: RAL 5009 207A (ISO 12944 - C2)
Grounding Lugs: Single
Fan Cover material: Steel
Tropicalized Painting: Without
Fan material: Plastic
Bearing cap: Yes- Bearing Cap
Balancing Method: 1/2 Key
Drip Cover: Without
Overload protector (phenolic): Without overload protector
Connection Cables Quantity: 6
|
