VILH. PEDERSEN 12" x 51" Universal Milling Machine PU2
VILH. PEDERSEN

12" x 51" Universal Milling Machine PU2

SKU: 157007
Price:
$4,900 CAD

Shipping calculated at checkout

Stock:
Only 1 unit left
Make an Offer

Need An Answer Now?

604-449-1880

Description

Used Vilh. Pedersen heavy-duty universal milling machine manufactured in Hoeng, Denmark. The machine features a rigid knee-type construction, vertical geared milling head, large T-slot worktable, manual axis controls, selectable feed rates, integrated work light, coolant plumbing and an included machine vise. A separate Polygon 15 kVA, three-phase transformer is also included, rated for 480 V primary and 206/120 V secondary power.
Specifications
Model PU2
S/N: 139889
Condition Used
General
Spindle Taper 40
Cross Travel (Table) 36" x 11" x 20" "
Table Size 12" x 51"
Speed 42-1,000 rpm
Other Specifications

Includes transformer and cabinet (everything in pictures)

Milling machine:

Operation: Manual

Spindle Configuration: Vertical milling head

Spindle Speeds: Multi-speed geared spindle

Table Type: Rectangular T-slot worktable

Table Travel: Manual longitudinal, cross and vertical movement

Feed System: Selectable mechanical table feeds

Spindle Quill: Manual feed

Included Workholding: Machine vise

Mounting: Floor-standing machine

Transformer

Manufacturer: Polygon

Transformer Type: Dry-type 3-phase transformer

Rated Capacity: 15 kVA

Frequency: 60 Hz

High Voltage: 480 V

Low Voltage: 206/120 V

BIL: 10 kV

Enclosure: Ventilated floor-standing enclosure
