Description
| Specifications | |
|---|---|
| Model | G3K32S25-WV8AWN |
| S/N: | 82D07771001 |
| Made In | UNITED STATES |
| Condition | Used | General |
| Current Type | AC |
| Horsepower | 2 hp |
| Alt. Horsepower | 208-460 hp |
| Voltage | 460 volts |
| Phase | 3-phase |
| RPM | 72 rpm |
| Frame | 7.79 |
| Other Specifications |
|---|
|
Motor Type: Induction Frame Size: 7.79 in Output Power: 2 HP Frequency (Hz): 60 Shaft/Gear Type: Parallel Shaft Gearhead Gear Ratio (X:1): 25 :1 Mount: Flange Mount Output Shaft Diameter: 1-1/4 in. Type: Terminal Box Rated Torque: 1673 lb/in Rated Speed (rpm): 72 Permissible Overhung Load: 991.40 lb Insulation Class: Class V Degree of Protection: IP65 |
