Description
| Specifications | |
|---|---|
| Model | 140MG-G8P-C30-KA |
| Made In | ITALY |
| Condition | Surplus New | General |
| Amps | 30 amps |
| # of Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 347/600 volts |
| Phase | Multi-phase |
| Other Specifications |
|---|
|
Type of control element: Toggle Rated impulse withstand voltage (Uimp): 8 kV Frame size: 125 A Magnetic trip current: Cam setting I: 330 A Hp rating: 5 Hp @ 230V, 3-phase Electrical life cycle: 8000 @ 415V AC Instantaneous trip setting: 3 to 125 A Position of connection for main current circuit: Front side Type of electrical connection of main circuit: Screw connection Interrupting rating/breaking capacity: 35...65 kA at 480V |
