Description
| Specifications | |
|---|---|
| Model | KDKS1/EN4 |
| Made In | CANADA |
| Condition | Used |
| Other Specifications |
|---|
|
Connection position: Sideways Closing plate required: Yes Length: 73.5 mm Height at lowest possible mounting height: 65 mm Width/grid dimension: 8 mm Inflammability class of insulation material according to with UL94: V2 Operating temperature: 100 °C Material insulation body: Thermoplastic Mounting method: DIN rail (top hat rail) 35 mm Type of fuse insert: G-fuse 5x20 mm Number of levels: 2 Rated voltage: 500 V Type of electrical connection 1: Screw connection Rated current In: 6.3 A Connectable conductor cross section multi-wired: 4 sq. mm Connectable conductor cross section solid-core: 4 sq. mm Connectable conductor cross section fine-strand with cable end sleeve: 4 sq. mm Connectable conductor cross section fine-strand without cable end sleeve: 4 sq. mm |
