Description
| Specifications | |
|---|---|
| Model | RNG-500 |
| Condition | Surplus New | General |
| Length | 1640 ft |
| Other Specifications |
|---|
|
Cable Type: Radiating Coaxial Cable Application: Underground Mining Communication Systems Compatible Systems: SMARTCOM 150 and SMARTCOM 150IS Nominal Reel Length: 500 m // 1640 ft Cable Outer Diameter: 15.5 mm // 0.610 in. Characteristic Impedance: 75 Ohms +/- 3 Ohms Inner Conductor: Annealed Copper Wire Dielectric Material: Gas-Foam Polyethylene Outer Conductor: Stranded Copper Inner Jacket: Black Polyethylene Outer Jacket: Yellow Flame-Resistant PVC Minimum Bend Radius: 1 m // 3.3 ft Maximum Voltage: 48V RMS Maximum Center Conductor Current: 8A RMS Cable Weight: 0.23 kg/m // 0.155 lbs/ft Standard Reel Diameter: 29 in. // 737 mm Standard Reel Height: 20 in. // 508 mm |
