Description
| Specifications | |
|---|---|
| Model | MSR100X12 |
| Condition | Surplus New |
| Other Specifications |
|---|
|
Equivalent Bearing Nut: AN-20
Inside Diameter: 3.93701"
TPI: 12
Axial Dynamic Load, lbf (kN): 46,090 (205)
Axial Static Load, lbf (kN): 60,920 (271)
Clamp Screw (SHCS): M6x22
No. of Screws: 6
Clamping Screw Torque, lb-in (Nm): 664 (75)
Moment of Inertia, lb-in² (kg-cm²): 13.27 (38.84)
Calculation Factor A (mm): 6.020
Calculation Factor B (N): 9,180
|
