Description
| Specifications | |
|---|---|
| Model | 2864655 |
| Condition | Used |
| Other Specifications |
|---|
|
No. of channels: 2 Electrical isolation: 2-way isolation Electrical isolation between input and output: yes Limit frequency (3 dB): 75 Hz Maximum power dissipation for nominal condition: 64 mW Signal transmission behavior: In = Out Step response (10-90%): 5 ms (at 600 ohm load) Maximum temperature coefficient: 0.002 % / K (of measured value / 100 ohm load) Temperature coefficient, typical: < 0.002 % / K (of measured value / 100 ohm load) Maximum transmission error: 0.1 % (of final value) Additional error, load-dependent: < 0.03 % (of measured value / 100 ohm load) Electrical isolation: Input/output Rated insulation voltage: 50 V AC/DC Test voltage: 1.5 kV AC (50 Hz, 60 s) Supply voltage range: loop-powered, no external supply necessary Power consumption: 34 mW (per channel) |
