Description
Phoenix Contact QUINT-PS-120AC/12DC/10/F industrial switching power supply, manufacturer part number 2938167. Designed to convert 120VAC input power into regulated 12VDC output at up to 10A (120W). Features DIN-rail mounting, adjustable output voltage, and a compact industrial enclosure for control cabinet applications. The manufacturer identifies this model as a primary switched-mode power supply with an integrated filter.
| Specifications | |
|---|---|
| Model | QUINT-PS-120AC/12DC/10/F |
| Made In | SLOVAK REPUBLIC |
| Condition | Surplus New | General |
| Type | Switched Mode | Electrical |
| Output Capacity | 12 Volts |
| Voltage | 120 volts |
| Frequency | 647-3 Hz |
| Other Specifications |
|---|
|
Manufacturer Part Number: 2938167 Series: QUINT POWER Product Type: Primary Switched-Mode Power Supply Input Voltage Range: 98-132VAC Input Frequency: 47-63Hz Input Current: Approximately 1.8A Output Current: 10A Rated Output Power: 120W Output Voltage Adjustment: 11.5-18VDC Efficiency: Greater than 82% Residual Ripple: 150mV peak-to-peak Input Fuse: 6.3A slow-blow, internally soldered Power Indicator: LED Mounting Type: DIN Rail NS 35 Connection Type: Pluggable Screw Terminals Enclosure Material: Metal Protection Rating: IP20 Operating Temperature: 0°C to 70°C |
